C70 Case IH Tractor 12-1/4" Single Stage Clutch Kit Assembly
$550.00
This Is a New 12-1/4’’ Single Stage Clutch Kit Assembly
The Kit Comes With
12-1/4’’ Diaphragm Pressure Plate
12-1/4’’ Clutch Disc with Seven Pads 1-1/8’’ 10 Spline Hub
Release Bearing OD 4.001” ID 2.374” Thickness 0.836”
Pilot Bearing OD 1.850” ID .787” Thickness .551”
Alignment Tool Large Spline 1-5/8’ 10 Spline Small Spline 1-1/8” 10 Spline
Pilot Diameter 0.787”
Flat Flywheel Step
